Inconel 600 Bolts

Inconel 600 Bolts

Inconel 600 Bolts is a Nickel Bolts-chromium composite utilized for applications that require erosion and high temperature opposition. This Nickel Bolts amalgam was intended for administration temperatures from cryogenic to lifted temperatures in the scope of 2000° F. It is non-attractive, has incredible mechanical properties, and presents the alluring mix of high quality and great weldability under a wide scope of temperatures. The high Nickel Bolts content in Inconel 600 Bolts empowers it to hold significant opposition under lessening conditions, makes it impervious to consumption by various natural and inorganic mixes, gives it superb protection from chloride-particle push erosion breaking and furthermore gives astounding protection from soluble arrangements. Average uses of this Nickel Bolts compound incorporate the substance, mash and paper, aviation, atomic designing and warmth treating businesses.

inconel-600-manufacturer-supplier-importer-exporter-stockholder

Fabrication with Inconel 600 Bolts : Alloy 600 can be both hot shaped and cold framed utilizing ordinary procedures. Hot working ought to be performed between 1600° F and 2250° F staying away from any work between1200-1600° F in light of the fact that the malleability diminishes in this temperature run. Welding Alloy 600 can be accomplished by means of protected metal-circular segment welding, TIG, and MIG.

Inconel 600 Bolts is a Nickel Bolts-chromium composite with great oxidation opposition at higher temperatures, with great obstruction in carburizing and chloride containing conditions.

Inconel 600 Bolts is a Nickel Bolts-chromium composite intended for use from cryogenic to raised temperatures in the scope of 2000 deg F(1093 deg C). The high Nickel Bolts substance of the composite empowers it to hold extensive obstruction under diminishing conditions and makes it impervious to consumption by various natural and inorganic mixes. The Nickel Bolts content gives it amazing protection from chloride-particle push consumption breaking and furthermore gives superb protection from basic arrangements.

Its chromium content gives the combination protection from sulfur mixes and different oxidizing conditions. The chromium substance of the composite makes it better than economically unadulterated Nickel Bolts under oxidizing conditions. In solid oxidizing arrangements like hot, concentrated nitric corrosive, 600 has poor opposition. Combination 600 is generally un-assaulted by the larger part of nonpartisan and soluble salt arrangements and is utilized in some harsh conditions. The composite opposes steam and blends of steam, air and carbon dioxide.

Amalgam 600 is non-attractive, has phenomenal mechanical properties and a blend of high quality and great usefulness and is promptly weldable. Inconel 600 Bolts displays cold framing qualities typically connected with chromium-Nickel Bolts hardened steels.

Run of the mill consumption applications incorporate titanium dioxide generation (chloride course), perchlorethylene combinations, vinyl chloride monomer (VCM), and magnesium chloride. Compound 600 is utilized in concoction and sustenance handling, warm treating, phenol condensers, cleanser produce, vegetable and unsaturated fat vessels and some more.



Chemical composition OF Inconel 600 Bolts


%

Ni

Cr

Fe

C

Mn

Si

S

Cu

min

72.0

14.0

6.0






max


17.0

10.0

0.15

1.00

0.50

0.015

0.50



physical PROPERTIES of Inconel 600 Bolts

Density

8.47 g/cm3

Melting range

1354-1413℃



ASTM Specifications of Inconel 600 Bolts

Pipe Smls Pipe Welded Tube Smls Tube Welded Sheet/Plate Bar Forging Fitting Wire
B167 B517 B163 B516 B168 B166 B564 B366



Mechanical Properties of Inconel 600 Bolts

Product Form Condition Tensile (ksi) .2% Yield (ksi) Elongation (%) Hardness (HRB)
Rod & Bar Cold-Drawn 80-100 25-50 35-55 65-85
Rod & Bar Hot-Finished 80-100 30-50 35-55 65-85
Tube & Pipe Hot-Finished 75-100 25-50 35*55 -
Tube & Pipe Cold-Drawn 80-100 25-50 35-55 88 Max
Plate Hot-Rolled 80-105 30-50 35-55 65-85
Sheet Cold-Drawn 80-100 30-45 35-55 88 Max



Types of Inconel Bolts

Inconel Hex Head Bolt Inconel Alloy Hex Head Bolts
Inconel Hex Head Bolt
600 Inconel Hex Head Bolt
Inconel Square Bolt Inconel Alloy Square Bolts
Inconel Square Bolt
600 Inconel Square Bolt
Inconel U Bolt Inconel Alloy U Bolts
Inconel U Bolt
600  Inconel U Bolt
Inconel Eye Bolt Inconel Alloy  Eye Bolts
Inconel Eye Bolt
600  Inconel Eye Bolt
Inconel T Bolt Inconel Alloy T Bolts
Inconel T Bolt
600 Inconel T Bolt
Inconel Hex Bolt Inconel Alloy Hex Bolts
Inconel Hex Bolt
600 Inconel Hex Bolt
Inconel Lag Bolt Inconel Alloy Lag Bolts
Inconel Lag Bolt
600 Inconel Lag Bolt
Inconel Counter sunk Bolt Inconel Alloy Counter sunk Bolts
Inconel Counter sunk Bolt
600 Counter sunk Bolt



Characteristics of Inconel 600 Bolts

»  Resistant to a wide range of corrosive media.
»   Virtually immune to chlorine ion stress corrosion cracking
»   Non-magnetic
»   Excellent mechanical properties
»   High strength and good weldability under a wide range of temperatures



Other Grades of Inconel Bolts

  • Inconel 600 Bolt
  • Inconel 601 Bolt
  • Inconel 625 Bolt
  • Inconel 718 Bolt
  • Incoloy 800 / 800H / 800HT Bolt
  • Incoloy 825 Bolt
  • Incoloy 925 Bolt
  • Incoloy 330/ SS 330/ Ra 330 Bolt



Applications of Inconel 600 Bolts

»   Chemical industry
»   Aerospace
»   Heat treating industry
»   Pulp and paper industry
»   Food processing
»   Nuclear Engineering
»   Gas turbine components
