Titanium Grade 5 Bolts

Titanium Grade 5 Bolts

Titanium bolts are best known for being solid, lightweight and erosion safe. One property that emerges when contrasted with other metal bolts is that titanium bolts have the most astounding solidarity to-weight proportion with a thickness of 4.51 g/cm3. For instance, titanium grade 5 is multiple times more grounded than 316 hardened steel at about a large portion of the load. This makes titanium jolts perfect for applications that require both delicacy of weight and amazing quality, for example, oil and gas (down-gap), military and wearing merchandise.

titanium-grade-5-manufacturer-supplier-importer-exporter-stockholder

Rimco Overseas is one of the popular manufacturer and suppliers of Titanium Gr.5 Bolts, which is alloyed with 6% Aluminium and 4% Vanadium and is commonly known as Ti 6Al-4V. Meanwhile, the essential difference between Ti6Al4V ELI (grade 23) and Ti6Al4V (grade 5) is the reduction of oxygen content to 0.13% (maximum) in grade 23. Like most titanium alloys, Titanium Gr.5 Hex Bolts has outstanding resistance to corrosion in most natural and many industrial process environments. One of the most important characteristics of Titanium Gr.5 Heavy Hex Bolts, though, is that it is heat treatable and most can even be welded. Neither grade of Titanium Gr.5 Square Bolts has corrosion properties quite as good as CP titanium, but both are corrosion resistant in seawater, oxidizing acids, aqueous chlorides, wet chlorine gas, and sodium hypochlorite. By extensively qualifying this process, we can consistently deliver high quality of Titanium Gr.5 Round Head Bolts to medical market and other markets with critical performance requirements.

Titanium Gr.5 Hex Screws is a two stage alpha and beta review of titanium and is the most broadly utilized of all the titanium levels. Titanium Gr.5 Hex Cap Screws is the most normally utilized composite. Titanium Gr.5 Socket Cap Screws is altogether more grounded than other economically unadulterated titanium while as yet holding a similar solidness and warm properties (barring warm conductivity). Our mastery in worldwide coordinations empowers us to source Titanium Gr.5 Allen Cap Screws from anyplace on the planet in merely days and give quick delivering answers for every one of our clients, whichever nation they are in. Purchase Titanium Grade 5 Bolts at reasonable rates from us.

Unlike to Grade 2 which is a monetarily unadulterated titanium, Grade 5 is a titanium alpha-beta composite, which incorporates 6% aluminum (alpha stabilizer) and 4% vanadium (beta stabilizer). Otherwise called Ti 6Al-4V, Titanium Grade 5 is the most regularly utilized type of titanium, representing half of titanium around the world. In spite of the fact that it offers marginally less erosion opposition than unalloyed Grade 2, Titanium Grade 5 latches are basic due to their better quality than weight proportion being multiple times more grounded than 316 treated steel at almost a large portion of the load. Contrasted with Grade 2,Titanium Grade 5 is about 2x more grounded. Notwithstanding its quality advantages over monetarily unadulterated evaluations, it likewise gives about 60% lower warm conductivity. Become familiar with titanium review 5 science and details.



Titanium Grade 5 Bolts Specifications

Specifications ASTM B 348 ASME SB 348
Standard DIN, ASTM, BS and all International Standards
Length 3 mm to Gr 2 mm
Size M3 – M56 | 3/6″ to 2″ | Custom Sizes
Type Hex Head Bolts, Square Bolts, U bolts, Eye bolts, T bolt, Hex Bolt, Lag Bolts, Counter sunk Bolts, Hex Head nuts, Square nuts, Lock nuts, Eye nuts, wing nuts, T nuts, Panel Nuts, Coupling Nuts, Dome nuts, Acorn Nuts.



Types of Titanium Grade 5 Bolts

Titanium Grade 5 Hex Head Bolt Titanium Grade 5 Alloy Hex Head Bolts
Titanium Grade 5 Hex Head Bolt
ASTM B348 Titanium Grade 5 Hex Head Bolt
Titanium Grade 5 Square Bolt Titanium Grade 5 Alloy Square Bolts
Titanium Grade 5 Square Bolt
ASTM B348 Titanium Grade 5 Square Bolt
Titanium Grade 5 U Bolt Titanium Grade 5 Alloy U Bolts
Titanium Grade 5 U Bolt
ASTM B348 Titanium Grade 5 U Bolt
Titanium Grade 5 Eye Bolt Titanium Grade 5 Alloy Eye Bolt
Titanium Grade 5 Eye Bolts
ASTM B348 Titanium Grade 5 Eye Bolt
Titanium Grade 5 T Bolt Titanium Alloy Grade 5 T Bolts
Titanium Grade 5 T Bolt
ASTM B348 Titanium Grade 5 T Bolt
Titanium Grade 5 Hex Bolt Titanium Grade 5 Alloy Hex Bolt
Titanium Grade 5 Hex Bolts
ASTM B348 Titanium Grade 5 Hex Bolt
Titanium Grade 5 Lag Bolt Titanium Grade 5 Alloy Lag Bolts
Titanium Grade 5 Lag Bolt
ASTM B348 Titanium Grade 5 Lag Bolt
Titanium Grade 5 Counter sunk Bolt Titanium Grade 5 Alloy Counter sunk Bolt
Titanium Grade 5 Counter sunk Bolts
ASTM B348 Titanium Grade 5 Counter sunk Bolt





Chemical Composition of Titanium Grade 5 Bolts

Element Percent By Weight
Ti Titanium 90%
Al Aluminum 6%
V Vanadium 4%
C Carbon < 0.10%
O Oxygen < 0.20%
N Nitrogen < 0.05%
H Hydrogen < 0.0125%
Fe Iron < 0.3%



Physical Properties of Titanium Grade 5 Bolts

Atomic Volume (average) 0.01 0.011 m3/kmol 610.237 671.261 in3/kmol
Density 4.429 4.512 Mg/m3 276.494 281.675 lb/ft3
Energy Content 750 1250 MJ/kg 81254 135423 kcal/lb
Bulk Modulus 96.8 153 GPa 14.0396 22.1908 106 psi
Compressive Strength 848 1080 MPa 122.992 156.641 ksi
Ductility 0.05 0.18 0.05 0.18 NULL
Elastic Limit 786 910 MPa 114 131.984 ksi
Endurance Limit 529 566 MPa 76.7249 82.0913 ksi
Fracture Toughness 84 107 MPa.m1/2 76.4439 97.375 ksi.in1/2
Hardness 3370 3730 MPa 488.777 540.991 ksi
Loss Coefficient 0.001 0.002 0.001 0.002 NULL
Modulus of Rupture 786 1080 MPa 114 156.641 ksi
Poisson's Ratio 0.31 0.37 0.31 0.37 NULL
Shear Modulus 40 45 GPa 5.80151 6.5267 106 psi
Tensile Strength 862 1200 MPa 125.023 174.045 ksi
Young's Modulus 110 119 GPa 15.9541 17.2595 106 psi
Glass Temperature K °F
Latent Heat of Fusion 360 370 kJ/kg 154.771 159.071 BTU/lb
Maximum Service Temperature 620 690 K 656.33 782.33 °F
Melting Point 1878 1933 K 2920.73 3019.73 °F
Minimum Service Temperature 0 K -459.67 °F
Specific Heat 553 570 J/kg.K 0.427944 0.441099 BTU/lb.F
Thermal Conductivity 7.1 7.3 W/m.K 13.2914 13.6658 BTU.ft/h.ft2.F
Thermal Expansion 8.7 9.1 10-6/K 15.66 16.38 10-6/°F
Breakdown Potential MV/m V/mil
Dielectric Constant NULL
Resistivity 168 170 10-8 ohm.m 168 170 10-8 ohm.m

Environmental Properties of Titanium Grade 5 Bolts

  Resistance Factors
1=Poor 5=Excellent
Flammability 5
Fresh Water 5
Organic Solvents 5
Oxidation at 500C 4
Sea Water 5
Strong Acid 4
Strong Alkalis 4
UV 5
Wear 3
Weak Acid 5
Weak Alkalis 5





Other Grades of Titanium Grade 5 Bolts

  • Titanium Gr 1 Bolts
  • Titanium Gr 2 Bolts
  • Titanium Gr 3 Bolts
  • Titanium Gr 5 Bolts
  • Titanium Gr 7 Bolts
  • Titanium Gr 11 Bolts



Applications of Titanium Grade 5 Bolts

»   Aerospace structures
»   Base plates
»   Fasteners
»   Chemical processing
»   Medical implants
